Description

Manufactured for use in potentially explosive atmospheres, the PRE316MY complies with ATEX and IECEx requirements and is suitable for installation in both gas and dust hazardous areas.

Key Features

• 16A rated current
• 2 Pole + Earth (2P+E) configuration
• Operating voltage: 110-130V
• Mobile socket design
• ATEX & IECEx certified
• Increased Safety (Ex e) design
• Suitable for Zone 1 and Zone 2 gas hazardous areas
• Suitable for Zone 21 and Zone 22 dust hazardous areas
• Equipment Group: II 2 GD
• IP66 ingress protection
• IK09 / IK10 impact resistance
• Robust industrial construction
• Reliable and secure electrical connection

Technical Specifications

Parameter	Specification
Model	PRE316MY
Brand	Appleton
Product Type	Mobile Socket
Current Rating	16A
Pole Configuration	2P + E
Voltage Range	110-130V
Hazardous Area Certification	ATEX / IECEx
Equipment Group	II 2 GD
Gas Zones	Zone 1, Zone 2
Dust Zones	Zone 21, Zone 22
Protection Rating	IP66
Impact Resistance	IK09 / IK10

Applications

Suitable for electrical power connections in hazardous locations requiring ATEX and IECEx certified equipment, including:

• Hazardous industrial facilities
• Chemical processing areas
• Manufacturing plants
• Storage facilities
• Dust hazardous environments
• Areas classified as Zone 1, Zone 2, Zone 21, and Zone 22

Benefits

• Enhanced safety in hazardous environments
• Excellent protection against dust and water ingress
• High impact resistance for demanding industrial applications
• Reliable power connection under harsh operating conditions
• Internationally recognized ATEX and IECEx certification

Certifications & Compliance

• ATEX Certified
• IECEx Certified
• Equipment Group II 2 GD
• IP66 Rated
• IK09 / IK10 Impact Protection
